Product Summary
The CNY17F-4 is a 6-PIN DIP optocoupler for power supply applications . The CNY17F-4 consist of a gallium arsenide LED optically coupled to a silicon phototransistor in a dual-in-line package. Applications are (1)Switchmode Power Supplies (Feedback Control); (2)AC Line/Digital Logic Isolation; (3)Interfacing and coupling systems of different potentials and impedances.
Parametrics
CNY17F-4 absolute maximum ratings: (1)Forward Current Continuous IF: 100 mA; (2)Forward Current Peak (PW = 1μs, 300pps)IF(pk): 1 A; (3)Reverse Voltage VR: 6 Volts; (4)LED Power Dissipation @ TA = 25°C PD: 140 mW; (5)Emitter-Collector Voltage VECO: 7 Volts; (6)Detector Power Dissipation @ TA = 25°C PD: 200 mW; (7)Ambient Operating Temperature Range TOPR: -55 to +100 °C; (8)Storage Temperature Range TSTG: -55 to +150 °C; (9)Lead Soldering Temperature TSOL: 260 °C.
Features
CNY17F-4 features: (1)Closely Matched Current Transfer Ratio (CTR)Minimizes Unit-to-Unit Variation; (2)Narrow (CTR)Windows that Translate to a Narrow and Predictable Open Loop Gain Window; (3)Very Low Coupled Capacitance along with No Chip to Pin 6 Base Connection for Minimum Noise Susceptibility; (4)To order devices that are tested and marked per VDE 0884 requirements, the suffix .300 must be included at the end of part number. e.g. MOC8101.300 VDE 0884 is a test option.
Diagrams
