Product Summary

The D442012LGY-B85X-MJH is a Rectifier Diode.

Parametrics

D442012LGY-B85X-MJH absolute maximum ratings: (1)repetitive peak reverse voltage, VRRM: 1600 V; (2)RMS forward current, IFRMSM: 10350 A; (3)mean forward current, IFAVM: 4650 A; (4)surge forward current, IFSM: 88 kA; (5)I2t-value，I2t 38, 7-106 A2s.

Features

D442012LGY-B85X-MJH features: (1)forward voltage: max 1.0 V; (2)threshold voltage: 0.62 to 7 V; (3)forward slope resistance: 0.069 to 0.075 m; (4)reverse current: 200 mA; (5)recovered charge: max 1.75 mAs.

Diagrams

D442012LGY-B85X-MJH block diagram
