Product Summary
The HD6473294F16 is a series of high-performance microcontrollers with a fast H8/300 CPU core and a set of on-chip supporting functions optimized for embedded control. The HD6473294F16 is include ROM, RAM, three types of timers, a serial communication interface, A/D converter, I/O ports, and other functions needed in control system configurations, so that compact, high-performance systems can be implemented easily. The series includes the HD6473294F16 with 60-kbyte ROM and 2-kbyte RAM.
Parametrics
HD6473294F16 absolute maximum ratings: (1)Supply voltage: –0.3 to +7.0 V; (2)Programming voltage: –0.3 to +13.5 V; (3)Input voltage Port 7: –0.3 to AVCC + 0.3 V; (4)Analog supply voltage: –0.3 to +7.0 V; (5)Analog input voltage: –0.3 to AVCC + 0.3 V .
Features
HD6473294F16 features: (1)Multiply instruction (8 bits ´ 8 bits); (2)Divide instruction (16 bits ÷ 8 bits); (3)Bit-accumulator instructions; (4)Register-indirect specification of bit positions.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() HD6473294F16V |
![]() |
![]() MCU 3/5V 32KB 64-QFP |
![]() Data Sheet |
![]()
|
|
||||||
