Product Summary
The ICE2A765 is an off-line SMPS current mode controller. The frequency reduction of the ICE2A765 is limited to 20kHz/21.5 kHz to avoid audible noise. In case of failure modes like open loop, overvoltage or overload due to short circuit the device switches in Auto Restart Mode which is controlled by the internal protection unit. By means of the internal precise peak current limitation, the dimension of the transformer and the secondary diode can be sized lower which leads to more cost effective for the overall system.
Parametrics
ICE2A765 absolute maximum ratings: (1)Drain Source Voltage: 650 V; (2)Pulsed drain current: 3.8 A; (3)Avalanche energy, repetitive tAR limited by max. Tj=150°C: 0.50 mJ; (4)Avalanche current, repetitive tAR limited by max. Tj=150°C: 7 A; (5)VCC Supply Voltage: -0.3 to 22 V; (6)FB Voltage VFB: -0.3 to 6.5 V: 150°C; (7)Storage Temperature: -50°C to +150°C; (8)ESD Robustness: 2 kV.
Features
ICE2A765 features: (1)650V/800V avalanche rugged CoolMOS; (2)Only few external components required; (3)Input Vcc Undervoltage Lockout; (4)67kHz/100kHz switching frequency; (5)Max duty cycle 72%; (6)Low Power Standby Mode to meet European Commission Requirements; (7)Thermal Shut Down with Auto Restart; (8)Overload and Open Loop Protection; (9)Overvoltage Protection during Auto Restart; (10)Adjustable Peak Current Limitation via external resistor; (11)Overall tolerance of Current Limiting < +/-5%; (12)Internal Leading Edge Blanking; (13)User defined Soft Start; (14)Soft driving for low EMI.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ICE2A765I |
Infineon Technologies |
Primary & Secondary Side PWM Controllers SMPS IC'S |
Data Sheet |
Negotiable |
|
||||||||||||
|
ICE2A765P |
Infineon Technologies |
Primary & Secondary Side PWM Controllers COOLSET IC CUR-MODE PWM CTRLR 650V |
Data Sheet |
|
|
||||||||||||
|
ICE2A765P2 |
Infineon Technologies |
Primary & Secondary Side PWM Controllers Off-Line SMPS Currnt Mode CTRLR 650V |
Data Sheet |
|
|
||||||||||||
