Product Summary
The 2sk4107 is a Toshiba field effect transistor. Application of the 2sk4107 includes Switching Regulator.
Parametrics
2sk4107 absolute maximum ratings: (1) Drain-source voltage VDSS: 500V; (2) Drain-gate voltage (RGS=20kΩ) VDGR: 500V; (3) Gate-source voltage VGSS: ±30V; (4) Drain current DC: 15A, IDP: 60A (Pulse) ; (5) Drain power dissipation (Tc = 25°C) , PD: 150W; (6) Single pulse avalanche energy EAS: 765mJ; (7) Avalanche current IAR: 15A; (8) Repetitive avalanche energy EAR: 15mJ; (9) Channel temperature Tch: 150°C; (10) Storage temperature range Tstg: -55 to 150°C.
Features
2sk4107 features: (1) Low drain-source ON resistance: RDS (ON) =0.33Ω; (2) High forward transfer admittance: |Yfs| = 8.5S (typ.) ; (3) Low leakage current: IDSS= 100μA (VDS= 500V) ; (4) Enhancement-mode: Vth= 2.0~4.0 V (VDS= 10 V, ID= 1 mA) .
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
2SK4107 |
Other |
Data Sheet |
Negotiable |
|
||||||
2SK4107(F,T) |
Toshiba |
MOSFET N-Ch FET VDSS 500V RDS 0.33 Ohm Yfs 8.5 |
Data Sheet |
Negotiable |
|
