Product Summary
The CY25811ZXCT is a spread spectrum clock generator. Applications are (1)Printers and MFPs; (2)LCD panels; (3)Digital copiers; (4)PDAs; (5)CD-ROM, VCD, and DVD; (6)Networking, LAN/WAN; (7)Scanners; (8)Modems; (9)Embedded digital systems.
Parametrics
CY25811ZXCT absolute maximum ratings: (1)VDD Supply Voltage: –0.5 to 4.6 V; (2)VIN Input Voltage Relative to V SS: –0.5 to VDD + 0.5 VDC; (3)TS Temperature, Storage Non Functional: –65 to 150 °C; (4)TA1 Temperature, Operating Ambient Functional, C-Grade: 0 to 70 °C; (5)TA2 Temperature, Operating Ambient Functional, I-Grade: –40 to 85 °C; (6)TJ Temperature, Junction Functional: 150 °C; (7)ESDHBM ESD Protection (Human Body Model)MIL-STD-883, Method 3015: 2000 V.
Features
CY25811ZXCT features: (1)4- to 32-MHz input frequency range; (2)4- to 128-MHz output frequency range; (3)Accepts clock, crystal, and resonator inputs; (4)Center and down spread modulation; (5)Low power dissipation; (6)Low cycle-to cycle jitter; (7)Available in 8-pin SOIC and TSSOP packages; (8)Commercial and industrial temperature ranges.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 CY25811ZXCT |
Cypress Semiconductor |
Phase Locked Loops (PLL) Advncd PREMIS Spread Spctrum Clk Synthszr |
Data Sheet |
Negotiable |
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
 |
CY25026ZC-1 |
Cypress Semiconductor |
Clock Generators & Support Products Spread Spectrum Clock Generator |
Data Sheet |
Negotiable |
|
||||||||||||
|
CY25026ZC-1T |
Cypress Semiconductor |
Clock Generators & Support Products Spread Spectrum Clock Generator |
Data Sheet |
Negotiable |
|
||||||||||||
|
CY25033KSXC-1 |
Cypress Semiconductor |
Phase Locked Loops (PLL) CY25033KSXC-1 |
Data Sheet |
Negotiable |
|
||||||||||||
|
CY25033KSXC-1T |
Cypress Semiconductor |
Phase Locked Loops (PLL) CY25033KSXC-1T |
Data Sheet |
Negotiable |
|
||||||||||||
|
CY25033SXC-1T |
Cypress Semiconductor |
Clock Generators & Support Products Spectrum Clk Genratr COM |
Data Sheet |
|
|
||||||||||||
|
CY2509 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
