ISL6298-2CR3Z-T

ISL6298-2CR3Z-T, single-cell Li-ion or Li-polymer battery charger, 7V, 500mA, DFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.50~5.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 500 :	5.20 / Piece
500 ~ 1000 :	4.60 / Piece
1000 ~ 1500 :	3.50 / Piece

PartNumber:: ISL6298-2CR3Z-T

Brand:: Intersil Corporation - Intersil | Pack: DFN | D/C: 08+

Availability:: Supply Ability: 10000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. harry's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-31

From Other Seller

Part Number:ISL6298-2CR3Z-T
US $3.50 - 5.20
Quantity:

piece

Product Summary

The ISL6298-2CR3Z-T is an integrated single-cell Li-ion or Li-polymer battery charger optimized for low current applications. The targeted applications include mini-disk (MD) players, Blue Tooth headsets, or other applications that use low-capacity battery cells. Applications are (1)MD Players, Blue-Tooth Headsets and MP3 Players; (2)Portable Instruments; (3)PDAs, Cell Phones and Smart Phones; (4)Stand-Alone Chargers.

Parametrics

ISL6298-2CR3Z-T absolute maximum ratings: (1)Supply Voltage (VIN): -0.3 to 7V; (2)Output Pin Voltage (VBAT): -0.3 to 5.5V; (3)Signal Input Voltage (TOEN, TIME, IREF, IMIN): -0.3 to 3.2V; (4)Output Pin Voltage (STATUS, FAULT): -0.3 to 7V; (5)Charge Current : 500mA; (6)ESD Rating Human Body Model: 1500V; (7)Machine Model: 150V; (8)Maximum Junction Temperature (Plastic Package): 150°C; (9)Maximum Storage Temperature Range: -65°C to 150°C; (10)Maximum Lead Temperature (Soldering 10s): 300°C.

Features

ISL6298-2CR3Z-T features: (1)Complete Charger for Single-Cell Li-ion Batteries; (2)Integrated Pass Element and Current Sensor; (3)No External Blocking Diode Required; (4)1% Voltage Accuracy; (5)Programmable Current Limit up to 450mA; (6)Programmable End-of-Charge Current; (7)Preconditioning with 20% Fast Charge Current; (8)10% Accuracy at 250mA; (9)Charge Current Thermal Foldback; (10)NTC Thermistor Interface for Battery Temperature Monitor; (11)User Programmable Safety Timer; (12)Ambient Temperature Range: -20°C to 70°C; (13)Thermally-Enhanced QFN Packages; (14)Pb-Free Plus Anneal Available (RoHS Compliant).
