Product Summary

The ISP2032E-110LT44 is a low voltage dual symmetrical transient voltage suppressor. The device is designed to protect ISDN applications against transients caused by lightning strikes and a.c. power lines. Offered in two voltage variants to meet battery and protection requirements they are guaranteed to suppress and withstand the listed international lightning surges in both polarities. Transients are initially clipped by breakdown clamping until the voltage rises to the breakover level, which causes the device to crowbar. The high crowbar holding current prevents d.c. latchup as the current subsides.

Parametrics

ISP2032E-110LT44 absolute maximum ratings: (1)V(BO)Breakover voltage: ±82 V V(BO); (2)Impulse breakover voltage: ±94 V; (3)I (BO)Breakover current: ±0.6 A; (4)VT On-state voltage: ±3 V; (5)dv/dt Critical rate of rise of off-state voltage: ±5 kV/µs; (6)ID Off-state current: ±10 μA; (7)Coff Off-state capacitance: 130 pF.

Features

ISP2032E-110LT44 features: (1)ESD protection to: IEC 61000-4-2 (ESD)±15kV (air), ±8kV (contact); IEC 61000-4-4 (EFT)40A (5/50ns); IEC 61000-4-5 (Lightning)12A (8/20μs).; (2)Array of surge rated diodes with internal EPD TVS diode; (3)Protects two I/O lines; (4)Low capacitance (<10pF)for high-speed interfaces; (5)Low leakage current (< 1μA); (6)Low operating voltage: 2.8V; (7)Solid-state technology.

Diagrams

ISP2032E-110LT44 pin connection
