IXDD430CI

30 Amp, Low-Side Ultrafast, MOSFET / IGBT Driver, TO220-5, 40 V, Low Propagation Delay Time

Rated 5 Rating 5 | reviews | Write a review

Price:: US $9.00~50.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $9.00~50.00

PartNumber:: IXDD430CI

Brand:: IXYS Corporation - ixys | Pack: DIP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. harry's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-17

From Other Seller

Part Number:IXDD430CI
US $9.00 - 50.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
MOC3063

US $0.32 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IXDD430CI is a high speed high current gate driver specifically designed to drive MOSFETs and IGBTs to their minimum switching time and maximum practical frequency limits. The IXDD430CI can source and sink 30A of peak current while producing voltage rise and fall times of less than 30ns. The input of the driver is compatible with TTL or CMOS and are fully immune to latch up over the entire operating range. Designed with small internal delays, cross conduction/current shoot-through is virtually eliminated in all configurations. The features and wide safety margin in operating voltage and power make the IXDD430CI unmatched in performance and value.

Parametrics

IXDD430CI absolute maximum ratings: (1)Supply Voltage: 40 V; (2)All Other Pins: -0.3 V to VCC + 0.3 V; (3)Power Dissipation, TAMBIENT ≤25 ℃, TO220 (CI), TO263 (YI): 2W; (4)Derating Factors (to Ambient), TO220 (CI), TO263 (YI): 0.016W/℃; (5)Storage Temperature: -65 ℃ to 150 ℃; (6)Lead Temperature (10 sec): 300 ℃.

Features

IXDD430CI features: (1)Built using the advantages and compatibility of CMOS and IXYS HDMOSTM processes; (2)Latch-Up Protected; (3)High Peak Output Current: 30A Peak; (4)Wide Operating Range: 8.5V to 35V; (5)Under Voltage Lockout Protection; (6)Ability to Disable Output under Faults; (7)High Capacitive Load Drive Capability: 5600 pF in <25ns; (8)Matched Rise And Fall Times; (9)Low Propagation Delay Time; (10)Low Output Impedance; (11)Low Supply Current.
