Product Summary

The KIA78L05 is a three terminal positive voltage regulator.

Parametrics

KIA78L05 absolute maximum ratings: (1)Input voltage: 35V; (2)power dissipation: 800mW; (3)operating junction temperature: -30 to 150℃; (4)operating temperature: -30 to 75℃; (5)storage temperature: -55 to 150℃.

Features

KIA78L05 features: (1)suitable for C-MOS, TTL, DTL, HTL, power supply; (2)internal short-circuit current limiting; (3)internal thermal overload protection; (4)maximum output current of 150mA; (5)packaged in TO-92L.

Diagrams

KIA78L05 block diagram
