Product Summary
The L7809ABD2T is a precision 1A regulator. It can provide local on-card regulation, eliminating the distribution problems associated with single point regulation. Each type employs internal current limiting, thermal shut-down and safe area protection, making it essentially indestructible.
Parametrics
L7809ABD2T absolute maximum ratings: (1)DC Input Voltage (for VO = 5 to 18V): 35 V; (2)DC Input Voltage (forVO = 20, 24V): 40 V; (3)Output Current Internally limited; (4)Power Dissipation Internally limited; (5)Operating Junction Temperature Range: -40 to 125°C; (6)Storage Temperature Range:- 65 to 150°C.
Features
L7809ABD2T features: (1)output current in excess of 1 A; (2)output voltagesof 5; 6; 8; 9; 12; 15; 18; 20; 24V; (3)thermal overloadprotection; (4)output transition soa protection; (5)2% output voltagetolerance; (6)guaranteed in extended temperature range.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 L7809ABD2T |
STMicroelectronics |
Linear Regulators - Standard 9.0V 1.0A Positive |
Data Sheet |
Negotiable |
|
||||||||||||
|
L7809ABD2T-TR |
STMicroelectronics |
Linear Regulators - Standard 9.0V 1.0A Positive |
Data Sheet |
|
|
||||||||||||
