Product Summary
The LM30CIMM is a general purpose operational amplifier which features improved performance over industry standards like the LM709. Advanced processing techniques make possible an order of magnitude reduction in input currents, and a redesign of the biasing circuitry reduces the temperature drift of input current. This LM30CIMM offers many features which make its application nearly foolpro of: overload protection on the input and output, no latch-up when the common mode range is exceeded, and freedom from oscillations and compensation with a single 30 pF capacitor. The LM30CIMM has advantages over internally compensated amplifier in that the frequency compensation can be tailored to the particular application. For example, in low frequency circuits it can be overcompensated for increased stability margin.
Parametrics
LM30CIMM absolute maximum ratings: (1)Supply Voltage: ±18V; (2)Differential Input Voltage: ±30V; (3)Input Voltage: ±15V; (4)Output Short Circuit Duration: Continuous; (5)Operating Ambient Temp. Range: 0℃ to +70℃.
Features
LM30CIMM features: (1)Offset voltage 3 mV maximum over temperature; (2)Input current 100 nA maximum over temperature; (3)Offset current 20 nA maximum over temperature; (4)Guaranteed drift characteristics; (5)Offsets guaranteed over entire common mode and supply voltage ranges; (6)Slew rate of 10V/μs as a summing amplifier.
