Product Summary

The LP2950 and LP2951 are micropower voltage regulators with very low quiescent current (75μA typ.) and very lowdropout voltage (typ. 40mV at light loads and 380mV at100mA). They are ideally suited for use in battery-poweredsystems. Furthermore, the quiescent current of the LP2950/LP2951 increases only slightly in dropout, prolonging batterylife.
The 8-lead LP2951 isavailable in plastic, ceramic dual-in-line, LLP, or metal canpackages and offers additional system functions.

Parametrics

The absolute maximum ratings of LP2951ACM are
(1)Input Supply Voltage: -0.3 to +30V;
(2)SHUTDOWN Input Voltage,
Error Comparator Output Voltage, (Note 9),
FEEDBACK Input Voltage: -1.5 to +30V;
(3)Power Dissipation: Internally Limited;
(4)Junction Temperature (TJ): +150°C;
(5)Ambient Storage Temperature: -65° to +150°C;
(6)Soldering Dwell Time, Temperature:
Wave: 4 seconds, 260°C;
Infrared: 10 seconds, 240°C;
Vapor Phase: 75 seconds, 219°C

Features

The features of LP2951ACM can be summarized as
(1)5V, 3V, and 3.3V versions available;
(2)High accuracy output voltage;
(3)Guaranteed 100mA output current;
(4)Extremely low quiescent current;
(5)Low dropout voltage;
(6)Extremely tight load and line regulation;
(7)Very low temperature coefficient;
(8)Use as Regulator or Reference;
(9)Needs minimum capacitance for stability;
(10)Current and Thermal Limiting;
(11)Stable with low-ESR output capacitors (10mΩ to 6Ω)

Diagrams

<P><IMG alt="LP2951ACM Block Diagram" src="http://www.seekic.com/uploadfile/ic-mfg/201271020316954.jpg" border=0></P>
