Product Summary

The MT1389DE AM/FM Tuner Module is high-end products specifically designed to meet the demanding performance, market, and pricing targets of automotive customers. The MT1389DE AM/FM Tuners combine the low system integration effort of a standard “plug and play” module with outstanding features and absolute high-end performance. Applications are (1)High-end car radios; (2)High-end home radios.

Parametrics

MT1389DE absolute maximum ratings: (1)Current AM mode: 42 mA; (2)Current FM mode: 32 mA; (3)Voltage: 4.75 to 5.25 V; (4)Operating temperature Parametric temperature range: -40 +85 °C; (5)Storage temperature: -40 +95 °C.

Features

MT1389DE features: (1)World-standard AM/FM function; (2)Serial data bus-controlled; (3)Very fast PLL; (4)On-board EEPROM supports digital alignment for AM and FM; (5)IF counter information readable; (6)Programmable switching output; (7)Reference frequency output supports appropriate external signal processor (see the MT1384WFC Application Kit); (8)Horizontal or vertical housing available; (9)Lead free and RoHS compliant.
