Product Summary

The SN74AS32DR is a quadruple 2-input positive-or gate. It contains four independent 2-input positive-OR gates. They perform the Boolean functions Y = A.8226; B or Y = A + B in positive logic.

Parametrics

SN74AS32DR absolute maximum ratings: (1)Supply voltage range, VCC: 7 V; (2)Input voltage, VI: 7 V; (3)Operating free-air temperature range: 0°C to 70°C; (4)Storage temperature range:–65°C to 150°C.

Features

SN74AS32DR features: (1)Package Options Include Plastic Small-Outline (D) Packages, Ceramic Chip; (2)Carriers (FK), and Standard Plastic (N) and Ceramic (J) 300-mil DIPs.

Diagrams

SN74AS32DR pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SN74AS32DR
SN74AS32DR

Texas Instruments

Gates (AND / NAND / OR / NOR) Quadruple 2-Input Positive-OR Gates

Data Sheet

0-1730: $0.30
1730-2000: $0.28
2000-2500: $0.28
2500-5000: $0.27
SN74AS32DRE4
SN74AS32DRE4

Texas Instruments

Gates (AND / NAND / OR / NOR) Quadruple 2-Input Positive-OR Gates

Data Sheet

0-1730: $0.30
1730-2000: $0.28
2000-2500: $0.28
2500-5000: $0.27
SN74AS32DRG4
SN74AS32DRG4

Texas Instruments

Gates (AND / NAND / OR / NOR) Quad 2Input Pos OR Gates

Data Sheet

0-1730: $0.30
1730-2000: $0.28
2000-2500: $0.28
2500-5000: $0.27
