The STA516B is a monolithic quad half bridge stage in Multipower BCD Technology. The device can be used as dual bridge or reconfigured, by connecting CONFIG pin to Vdd pin, as single bridge with double current capability, and as half bridge (Binary mode) with half current capability.
Parametrics
STA516B absolute maximum ratings: (1)VCC, DC supply voltage (Pins 4,7,12,15): 60 V; (2)Vmax, Maximum voltage on pins 23 to 32: 5.5 V; (3)Top, Operating temperature range: 0 to 70℃; (4)Tstg, Tj, Storage and junction temperature: -40 to 150℃.
Features
STA516B features: (1)Minimum input output pulse width distortion; (2)200 mΩ RdsON complementary DMOS output stage; (3)CMOS compatible logic inputs; (4)Thermal protection; (5)Thermal warning output; (6)Under voltage protection.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 STA516B13TR |
STMicroelectronics |
Audio Amplifiers 65-Volt 7.5-amp QUAD Half-Bridge AMP |
Data Sheet |
|
|
||||||||||||
