The TDA4863J is a vertical deflection booster. And it needs a separate flyback supply voltage, so the supply voltages are independently adjustable to optimize power consumption and flyback time.
Parametrics
TDA4863J absolute maximum ratings: (1)supply voltage: 40 or 60 V; (2)flyback supply voltage: 60 V; (3)input voltage on pins 6 and 7: Vp1 V; (4)output voltage on pin 5: 62 V; (5)supply current: ±1.8 A; (6)output current (pin 5): ±1.8 A; (7)flyback current on pin 2: ±1.8 A; (8)storage temperature: -25 to +150 °C; (9)ambient temperature: -20 to +75 °C.
Features
TDA4863J features: (1)Power amplifier with differential inputs; (2)Output current up to 3 A (p-p); (3)High vertical deflection frequency up to 200 Hz; (4)High linear sawtooth signal amplification.
