Product Summary
The TDA8262HN is a Fully integrated satellite tuner.The direct conversion QPSK demodulator is the front-end receiver dedicated to digital TV broadcasting, satisfying both DVB-S and DBS TV standards. The wide range oscillator(from 950 MHz to 2175 MHz) covers the American, European and Asian satellite bands, as well as the SMA-TV US standard.
Parametrics
TDA8262HN absolute maximum ratings: (1)VCC1 Supply Voltage: 30 V; (2)VCC2 Flyback Generator Supply Voltage: 35 V; (3)V9 Frame Power Supply Voltage: 60 V; (4)I10NR Frame Output Current (non repetitive): ± 1.5 A; (5)I10 Frame Output Current (continuous): ± 1 A; (6)V17 Line Output Voltage (external): 60 V; (7)Ip17 Line Output Peak Current: 0.8 A; (8)IC17 Line Output Continuous Current: 0.4 A; (9)TSTG Storage Temperature: –40 to 150 ℃; (10)TJ Max Operating Junction Temperature: + 150 ℃; (11)TAMB Operating Ambient Temperature: 0 to 70 ℃.
Features
TDA8262HN features: (1)Direct line darlington drive; (2)Direct frame-yoke drive (± 1A); (3)Composite video signal input capability; (4)Frame output protection against short circuits PLL; (5)Video identification circuit; (6)Super sandcastle output; (7)Very few external components; (8)Very lowcost power package.
