UPG2009TB-E3

UPG2009TB-E3, S-Band high power SPDT switch, 0.15 W, 36 dBm, +6.0 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	3.00 / Piece
101 ~ 200 :	2.00 / Piece
201 ~ 300 :	1.00 / Piece

PartNumber:: UPG2009TB-E3

Brand:: NEC - Nec | Pack: SOIC | D/C: 11+

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. harry's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-06

From Other Seller

Part Number:UPG2009TB-E3
US $1.00 - 3.00
Quantity:

piece

Product Summary

The UPG2009TB-E3 is a S-Band high power SPDT switch. It can be used in (1)L-band digital cellular or cordless telephone; (2)BluetoothTM , W-LAN and WLL; (3)Short R ange W ireless. The device can operate from 500 MHz to 2.5 GHz, with low insertion loss and high isolation.

Parametrics

UPG2009TB-E3 absolute maximum ratings: (1)Control Voltage 1, 2: -6.0 to +6.0 V; (2)Input Power: 36 dBm; (3)Total Power Dissipation: 0.15 W; (4)Operating Ambient Temperature: -45 to +85°C; (5)Storage Temperature: -55 to +150°C.

Features

UPG2009TB-E3 features: (1)Low insertion l oss: 0.25 dB TYP. @ Vcont1/2 = 2.8 V/0 V, f = 1.0 GHz and 0.30 dB TYP. @ Vcont1/2 = 2.8 V/0 V, f = 2.0 GHz; (2)High isolation: 28 dB TYP. @ Vcont1/2 = 2.8 V/0 V, f = 2.0 GHz; (3)power HAN DLING : Pin (0.1dB) = 34 dBm TYP. @ Vcont1/2 = 2.8 V/0 V, f = 1.0 GHz; (4)bidirctonal, symmetrical; (5)6-pin super m minimold ld ld package (2.0 x 1.25 x 0.9 mm).
