Product Summary

The V10621N0A1-R is a ZNR transient/surge absorber. This device can be used in (1)Transistor, diode, IC, thyristor or triac semiconductor protection; (2)Surge protection in consumer electronic equipment; (3)Surge protection in communication, measuring or controller electronics; (4)Surge protection in electronic home appliances, gas or petroleum appliances.

Parametrics

V10621N0A1-R absolute maximum ratings: (1)Varistor Voltage: 620 V; (2)Maximum Allowable Voltage ACrms (V)Maximum Allowable Voltage DC (V): 385 V; (3)Clamping Voltage at 8/20μs: 1025; (4)Maximum Peak Current at 8/20μs(A): 3500.

Features

V10621N0A1-R features: (1)Large withstanding surge current capability in compact sizes; (2)Large “Energy Handling Capability” absorbing transient overvoltages in compact sizes; (3)Wide range of varistor voltages; (4)The standard products shown below have received UL, CSA and VDE standards: Varistor voltage 82 to 150V : UL, VDE; Varistor voltage 200V over : UL, VDE, CSA (cf. Application Notes for UL/VDE, CSA recognized parts on page 27); (5)RoHS compliant.

Diagrams

V10621N0A1-R dimension figure
