Product Summary
The JY5H-K is a Common Moder Filter. It is ideal for: personal computers, telephones, lans, isdns, digital pbxs, electronic games, ctvs, cd-rom drives, 8mm video equipment, and other electronic devices
Parametrics
JY5H-K absolute maximum ratings: (1)rated voltage edc: 50 V; (2)Rated current: 2 A; (3)Test voltage Edc: 250 V; (4)Insulation resistance: 100 mΩ; (5)Storage temperature range: –25 to +85°C.
Features
JY5H-K features: (1)a common mode filter for distortion-free removal of noise from transmitted signals. best common mode filter for transmission of high quality signals.; (2)best filter for countering the common mode noise resulting from data signal processing by pcs, phone equipment, etc.; (3)highly appropriate for ic board mounting due to dip type structure.; (4)due to a maximum current tolerance of 2a, can also be used to counter power line noise.
Diagrams
