Product Summary

The SRD-05VDC-SL-C is a bi-level led indicator. The super bright red source color devices are made with gallium aluminum arsenide red light emitting diode.



Parametrics

SRD-05VDC-SL-C absolute maximum ratings: (1)power dissipation: 75 mw; (2)dc forward current: 30 ma; (3)peak forward current [1]: 155 ma; (4)reverse voltage: 5 v; (5)operating temperature: -40°c to +85°c; (6)storage temperature: -40°c to +85°c.

Features

SRD-05VDC-SL-C features: (1)i.c. compatible.; (2)black case enhances contrast ratio.; (3)wide viewing angle.; (4)high reliability life measured in years.; (5)housing material: ppa.; (6)rohs compliant.

Diagrams

SRD-05VDC-SL-C pin connection
