Product Summary
The SKM50GB12T4 is an IGBT module. The applications are Switching (not for linear use), Switched mode power supplies, UPS, Three phase inverters for servo /AC motor speed control and Pulse frequencies also above 10 kHz.
Parametrics
SKM50GB12T4 absolute maximum ratings: (1)VCES: 600V; (2)VCGR: 600V; (3)IC: 70/50A; (4)ICM: 140/100A; (5)VGES: ±20V; (6)Ptot: 250W; (7)Tj, (Tstg): -40 to 150(125)℃; (8)Visol: 2500V.
Features
SKM50GB12T4 features: (1)N channel, homogeneous Silicon structure (NPT- Non punch-through IGBT); (2)Low tail current with low temperature dependence; (3)High short circuit capability, self limiting if term. G is clamped to E; (4)Pos. temp.-coeff. of VCEsat; (5)50 % less turn off losses; (6)0 % less short circuit current; (7)Very low Cies, Coes, Cres; (8)Latch-up free; (9)Fast & soft inverse CAL diodes; (10)Isolated copper baseplate using DCB Direct Copper Bonding Technology without hard mould; (11)Large clearance (10 mm) and creepage distances (20 mm).
Diagrams
