Product Summary
The SKM75GB12T4 is a fast IGBT4 module. Applications are (1)AC inverter drives; (2)UPS; (3)Electronic welders at fsw up to 20 kHz.
Parametrics
SKM75GB12T4 absolute maximum ratings: (1)VCES: 1200 V; (2)IC, Tj = 175 °C, Tc = 25 °C: 115 A; Tc = 80 °C: 88 A; (3)ICnom: 75 A; (4)ICRM, ICRM = 3xICnom: 225 A; (5)VGES: -20 to 20 V; (6)tpsc, VCC = 800 V, Tj = 150 °C: 10 μs; VGE ≤ 15 V, Tj = 150 °C: 10 μs; VCES ≤ 1200 V, Tj = 150 °C: 10 μs; (7)Tj: -40 to 175 °C.
Features
SKM75GB12T4 features: (1)IGBT4 = 4. Generation (Trench)IGBT; (2)VCEsat with positive temperature coefficient; (3)High short circuit capability, self limiting to 6 x ICNOM; (4)Soft switching 4. Generation CAL diode (CAL4).
Diagrams
