Product Summary

The FF150R12RT4 is a 34mm Module with fast Trench/Feldstopp IGBT4 and Emitter Controlled 4 diode. The applications of it are high frequency switching application, motor drives, UPS systems.

Parametrics

FF150R12RT4 absolute maximum ratings: (1)collector-emitter voltage:1200V; (2)DC-collector current:150A; (3)repetitive peak collector current:300A; (4)total power dissipation:790W; (5)gate-emitter peak voltage:±20V.

Features

FF150R12RT4 features: (1)extended operation temperature Tvj op; (2)low switching losses; (3)low VCEsat; (4)Tvj op=150℃; (5)VCEsat with positive temperature coefficient.

Diagrams

FF150R12RT4 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
FF150R12RT4
FF150R12RT4
Infineon Technologies
IGBT Modules IGBT 1200V 150A
Data Sheet
0-6: $55.20
6-10: $49.80
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
FF150R12KE3_B8
FF150R12KE3_B8
Infineon Technologies
IGBT Modules IGBT 1200V 150A
Data Sheet
0-6: $113.40
6-10: $102.00
FF150R12KE3G
FF150R12KE3G
Infineon Technologies
IGBT Modules 1200V 150A DUAL
Data Sheet
0-1: $75.44
1-10: $67.90
FF150R12KE3G_B2
FF150R12KE3G_B2
Infineon Technologies
IGBT Modules N-CH 1.2KV 225A
Data Sheet
0-6: $73.85
6-10: $66.47
FF150R12KS4
FF150R12KS4
Infineon Technologies
IGBT Modules 1200V 150A DUAL
Data Sheet
0-6: $82.62
6-10: $74.36
FF150R12KS4_B2
FF150R12KS4_B2
Infineon Technologies
IGBT Modules N-CH 1.2KV 225A
Data Sheet
0-6: $73.06
6-10: $65.75
FF150R12KT3G
FF150R12KT3G
Infineon Technologies
IGBT Modules N-CH 1.2KV 225A
Data Sheet
0-6: $73.85
6-10: $66.47
