Product Summary

The mrf5s19090h is an N-Channel Enhancement-Mode Lateral MOSFET. Designed for broadband commercial and industrial applications with frequencies up to 500 MHz. The high gain and broadband performance of the mrf5s19090h makes it ideal for large - signal, common- source amplifier applications in 28 volt base station equipment.

Parametrics

mrf5s19090h absolute maximum ratings: (1)Drain-Source Voltage, VDSS: -0.5 to +65 Vdc; (2)Gate-Source Voltage, VGS: -0.5, +15 Vdc; (3)Storage Temperature Range, Tstg: - 65 to +150℃; (4)Operating Junction Temperature, (1,2) TJ: 200℃.

Features

mrf5s19090h features: (1)Characterized with Series Equivalent Large-Signal Impedance Parameters; (2)Internally Matched for Ease of Use; (3)Qualified Up to a Maximum of 32 VDD Operation; (4)Integrated ESD Protection; (5)200℃ Capable Plastic Package; (6)RoHS Compliant; (7)In Tape and Reel. R1 Suffix = 500 Units per 44 mm, 13 inch Reel.

Diagrams

mrf5s19090h block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MRF5S19090HR3
MRF5S19090HR3


MOSFET RF N-CHAN 28V 18W NI-780

Data Sheet

Negotiable
MRF5S19090HR5
MRF5S19090HR5


MOSFET RF N-CHAN 28V 18W NI-780

Data Sheet

Negotiable
MRF5S19090HSR3
MRF5S19090HSR3


MOSFET RF N-CHAN 28V 18W NI-780S

Data Sheet

Negotiable
MRF5S19090HSR5
MRF5S19090HSR5


MOSFET RF N-CHAN 28V 18W NI-780S

Data Sheet

Negotiable
