Product Summary
The A1280XL-PQ160C an Integrator Series FPGA, which is designed to integrate system logic which is typically implemented in multiple CPLDs, PALs, and FPGAs.The A1280XL-PQ160C provides the features and performance required for today’s complex, high-speed digital logic systems. Based on Actel proprietary antifuse technology and 0.6-micron double metal CMOS process, the A1280XL-PQ160C offers a fine-grained, register-rich architecture with embedded dual-port SRAM and wide-decode circuitry.
Parametrics
A1280XL-PQ160C absolute maximum ratings: (1)DC Supply Voltage: –0.5 to +7.0 V; (2)Input Voltage: –0.5 to VCC +0.5 V; (3)Output Voltage: –0.5 to VCC +0.5 V; (4)Storage Temperature: –65 to +150℃.
Features
A1280XL-PQ160C features: (1)2,500 to 30,000 Logic Gates; (2)Up to 3Kbits Configurable Dual-Port SRAM; (3)Fast Wide-Decode Circuitry; (4)Up to 250 User-Programmable I/O Pins; (5)225 MHz Performance; (6)5 ns Dual-Port SRAM Access; (7)100 MHz FIFOs; (8)7.5 ns 35-Bit Address Decode.
Diagrams
