Product Summary

The C458G is a dual operational amplifier, specially designed for improving the tone control, which is most suitable for the audio application. Featuring noiseless, higher gain bandwidth, high output current and low distortion ratio, and it is most suitable not only for acoustic electronic parts of audio pre-amp and active filter, but also for the industrial measurement tools. It is also suitable for the head phone amp at higher output current, and further more, it can be applied for the handy type set operational amplifier of general purpose in application of low voltage single supply type which is properly biased of the input low voltage source.



Parametrics

C458G absolute maximum ratings: (1)Supply Voltage V + /V: ±18 V; (2)Input Voltage VIC: ±15 V; (3)Differential Input Voltage VID: ±30 V; (4)Output Current Io: ±50 mA; (5)Power Dissipation PD: 800 (DIP-8) mW; (6)Operating Temperature Range Topr: -40 to+85 °C; (7)Storage Temperature Range Tstg: -40 to +125 °C .

Features

C458G features: (1)Operating Voltage: (±2V to±18V); (2)Low Input Noise Voltage: (0.8μVrms typ.); (3)Wide Gain Bandwidth Product: (15MHz typ.); (4)Low Distortion: (0.0005% typ.); (5)Slew Rate: (5V/µs typ.); (6)Bipolar Technology .

Diagrams

C458G pin connection
