Product Summary

The CLA53104BW is a High Efficiency Thyristor. It is ideal for: (1)softstart ac motor control; (2)dc motor control; (3)power converter; (4)ac power control; (5)lighting and temperature control.


Parametrics

CLA53104BW absolute maximum ratings: (1)vrsm/dsm: 1300 V; (2)IR/D: 50 μA; (3)VT: 1.60 V; (4)rT: 7.7 mΩ; (5)TVJ: -40 to 150°C; (6)Ptot: 500 W; (7)CJ: 25 pF.

Features

CLA53104BW features: (1)Thyristor for line frequency; (2)Planar passivated chip; (3)Long-term stability.

Diagrams

CLA53104BW pin connection
