LM567

general purpose Tone Decoder, 9V, 20 to 1 frequency range, Immunity to false signals

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~5.00

PartNumber:: LM567

Brand:: National Semiconductor - NS | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. harry's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-16

From Other Seller

Part Number:LM567
US $0.10 - 5.00
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM567 is a general purpose tone decoder designed to provide a saturated transistor switch to ground when an input signal is present within the passband. The circuit LM567 consists of an I and Q detector driven by a voltage controlled oscillator which determines the center frequency of the decoder. External components are used to independently set center frequency, bandwidth and output delay. The applications of LM567 are: Touch tone decoding, Precision oscillator, Frequency monitoring and control, Wide band FSK demodulation, Ultrasonic controls, Carrier current remote controls, Communications paging decoders.

Parametrics

LM567 absolute maximum ratings: (1)Supply Voltage Pin: 9V; (2)Power Dissipation: 1100 mW; (3)V8: 15V; (4)V3: -10V; (5)V3: V4 + 0.5V; (6)Storage Temperature Range: -65℃ to +150℃; (7)Operating Temperature Range: 0℃ to +70℃; (8)Soldering Information: Dual-In-Line Package Soldering (10 sec.): 260℃; (9)Small Outline Package, Vapor Phase (60 sec.): 215℃; Infrared (15 sec.): 220℃.

Features

LM567 features: (1)20 to 1 frequency range with aexternal resistor; (2)Logic compatible output with 100 mA current sinking capability; (3)Bandwidth adjustable from 0 to 14%; (4)High rejectioof out of band signals and noise; (5)Immunity to false signals; (6)Highly stable center frequency; (7)Center frequency adjustable from 0.01 Hz to 500 kHz.
