Product Summary

The IRFP460PBF is an International Rectifier. The IRFP460PBF provides the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness. The TO-247 package is preferred for commercial-industrial applications where higher power levels preclude the use of TO-220 devices. The TO-247 is similar but superior to the earlier TO-218 package because its isolated mounting hole. The IRFP460PBF also provides greater creepage distances between pins to meet the requirements of most safety specifications.

Parametrics

IRFP460PBF absolute maximum ratings: (1)Drain-Source Voltage: 500V; (2)Gate-Source Voltage: ± 20V; (3)Continuous Drain Current VGS at 10 V: TC = 25℃: 20A, TC = 100℃: 13A; (4)Pulsed Drain Current: 80A; (5)Linear Derating Factor: 2.2 W/℃; (6)Single Pulse Avalanche Energyb: 960 mJ ; (7)Repetitive Avalanche Current: 20A ; (8)Repetitive Avalanche Energya: 28 mJ ; (9)Maximum Power Dissipation TC = 25℃: 280 W ; (10)Peak Diode Recovery dV/dt: 3.5 V/ns ; (11)Operating Junction and Storage Temperature Range: -55℃ to +150℃ ; (12)Soldering Recommendations (Peak Temperature) for 10 s: 300℃; (13)Mounting Torque 6-32 or M3 screw: 10 lbf·in, 1.1 N·m.

Features

IRFP460PBF features: (1)Dynamic dv/dt Rating; (2)Repetitive Avalanche Rated; (3)Isolated Central Mounting Hole; (4)Fast Switching; (5)Ease of Paralleling; (6)Simple Drive Requirements; (7)Lead-Free.

Diagrams

IRFP460PBF block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IRFP460PBF
IRFP460PBF

Vishay/Siliconix

MOSFET N-Chan 500V 20 Amp

Data Sheet

0-1: $2.11
1-10: $1.69
10-100: $1.54
100-250: $1.39
