Product Summary
The MC74HC4851A is an analog multiplexer/demultiplexer with injuection current effect control. The device is pin compatible to standard HC405x and MC1405xB analog mux/demux device, but features injection current effect control. This makes the MC74HC4851A especially suited for usage in automotive applications where voltages in excess of normal logic voltage are common. The MC74HC4851A utilizes low power silicon gate CMOS technology. The Channel Select and Enable inputs are compatible with standard CMOS outputs.
Parametrics
MC74HC4851A absolute maximum ratings: (1)VCC, Positive DC Supply Voltage (Referenced to GND): -5 to 7.0 V; (2)Vin, DC Input Voltage (Any Pin) (Referenced to GND): -5 to VCC + 0.5 V; (3)IDC, Current, Into or Out of Any Pin: 25 mA; (4)PD Power Dissipation in Still Air: 750mW; (5)Tstg, Storage Temperature Range: -5 to + 150 (6)TL, Lead Temperature, 1 mm from Case for 10 Seconds: 260°C.
Features
MC74HC4851A features: (1)Injection Current Cross-Coupling Less than 1mV/mA; (2)Pin Compatible to HC405X and MC1405XB Devices; (3)Power Supply Range (VCC - GND) = 2.0 to 6.0 V; (4)In Compliance With the Requirements of JEDEC Standard No. 7A; (5)Chip Complexity: 154 FETs or 36 Equivalent Gates; (6)Pb-Free Packages are Available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MC74HC4851A |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||||
 |
MC74HC4851AD |
ON Semiconductor |
Multiplexer Switch ICs Mux/Demux Injection |
Data Sheet |
Negotiable |
|
||||||||||||||
|
MC74HC4851ADG |
ON Semiconductor |
Multiplexer Switch ICs Mux/Demux Injection Current Effect CNTRL |
Data Sheet |
|
|
||||||||||||||
|
MC74HC4851ADR2G |
ON Semiconductor |
Multiplexer Switch ICs Mux/Demux Injection Current Effect CNTRL |
Data Sheet |
|
|
||||||||||||||
|
MC74HC4851ADTR2 |
ON Semiconductor |
Multiplexer Switch ICs Mux/Demux Injection |
Data Sheet |
Negotiable |
|
||||||||||||||
|
MC74HC4851ADR2 |
ON Semiconductor |
Multiplexer Switch ICs Mux/Demux Injection |
Data Sheet |
Negotiable |
|
||||||||||||||
|
MC74HC4851ADWR2G |
ON Semiconductor |
Multiplexer Switch ICs Mux/Demux Injection Current Effect CNTRL |
Data Sheet |
|
|
||||||||||||||
|
MC74HC4851ANG |
ON Semiconductor |
Multiplexer Switch ICs LOG CMOS MLTIPLXR ANALOG |
Data Sheet |
|
|
||||||||||||||
