MC74LCX08DR2

MC74LCX08DR2, high performance quad 2-input AND gate, +7.0 V, +/-100 mA, SOIC-14

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	3.00 / Piece
101 ~ 200 :	2.00 / Piece
201 ~ 300 :	1.00 / Piece

PartNumber:: MC74LCX08DR2

Brand:: ON SEMICONDUCTOR - ONS | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. harry's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-06

From Other Seller

Part Number:MC74LCX08DR2
US $1.00 - 3.00
Quantity:

piece

Product Summary

The MC74LCX08DR2 is a high performance quad 2-input AND gate.

Parametrics

MC74LCX08DR2 absolute maximum ratings: (1)DC supply voltage: -0.5 to +7.0 V; (2)DC input voltage: -0.5≤VI≤+7.0V; (3)DC output voltage: -0.5≤VO≤VCC + 0.5; (4)DC input current: -50 mA; (5)DC output current: -50 mA; (6)DC supply current: +/-100 mA; (7)DC Ground Current Per Ground Pin: +/-100 mA; (8)storage temperature: -65 to +150 °C.

Features

MC74LCX08DR2 features: (1)Designed for 2.3 V to 3.6 V VCC Operation; (2)5.0 V Tolerant Inputs - Interface Capability With 5.0 V TTL Logic; (3)LVTTL Compatible; (4)LVCMOS Compatible; (5)24 mA Balanced Output Sink and Source Capability; (6)Near Zero Static Supply Current (10 μA) Substantially Reduces System Power Requirements; (7)Latchup Performance Exceeds 500 mA; (8)ESD Performance: Human Body Model >2000 V Machine Model >200 V; (9)Pb-Free Packages are Available.
