MMBT2222A

MMBT2222A, 40 V, 1.0 A, 300 MHz, medium power amplifier, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.60~2.95 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 500 :	2.95 / Piece
500 ~ 1000 :	1.75 / Piece
1000 ~ 1500 :	0.60 / Piece

PartNumber:: MMBT2222A

Brand:: Fairchild Semiconductor - Fairchild | Pack: SOT | D/C: 07+

Availability:: Supply Ability: 10000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. harry's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-31

From Other Seller

Part Number:MMBT2222A
US $0.60 - 2.95
MMBT2222A-NL

US $0.02 - 0.02 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MMBT2222A is a medium power amplifier and switch requiring collector currents up to 500 mA. Sourced from Process 19.

Parametrics

MMBT2222A absolute maximum ratings: (1)VCEO Collector-Emitter Voltage: 40 V; (2)VCBO Collector-Base Voltage: 75 V; (3)VEBO Emitter-Base Voltage: 6.0 V; (4)IC Collector Current - Continuous: 1.0 A; (5)TJ, Tstg Operating and Storage Junction Temperature Range: -55 to +150 °C.

Features

MMBT2222A features: (1)fT Current Gain - Bandwidth Product IC = 20 mA, VCE = 20 V, f = 100 MHz: 300 MHz; (2)Cobo Output Capacitance VCB = 10 V, IE = 0, f = 100 kHz: 8.0 pF; (3)Cibo Input Capacitance VEB = 0.5 V, IC = 0, f = 100 kHz: 25 pF; (4)rb CC Collector Base Time Constant IC = 20 mA, VCB = 20 V, f = 31.8 MHz: 150 pS; (5)NF Noise Figure IC = 100 μA, VCE = 10 V, RS = 1.0 kΩ, f = 1.0 kHz: 4.0 dB; (6)Re(hie)Real Part of Common-Emitter High Frequency Input Impedance IC = 20 mA, VCE = 20 V, f = 300 MHz: 60 Ω.
