Product Summary

The DS2Y-SL2-DC5V is a miniature relay. It is intended for telecommunication equipment, office equipment, computer peripherals, security alarm systems, medical equipment.

Parametrics

DS2Y-SL2-DC5V specifications: (1)Arrangement: 2 Form C; (2)Initial contact resistance, max.: Max. 50 mΩ (By voltage drop 6 V DC 1A); (3)Contact material: Ag+Au clad; (4)Max. switching power: 60 W, 62.5 VA (resistive load); (5)Max. switching voltage: 220 V DC, 250 V AC; (6)Max. switching current: 2 A; (7)Max. carrying current: 3 A; (8)Minimum operating power: Approx. 98 mW (147 mW: 48 V); (9)Nominal operating power: Approx. 200 mW (300 mW: 48 V); (10)Mechanical: Min. 108; (11)Electrical: 105 (1 A 30 V DC), 105 (2 A 30 V DC); (12)Conditions for operation, transport and storage* Ambient temperature: –40℃ to +70℃, –40°F to +158°F, Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature); (13)Max. operating speed (at rated load): 60 cpm; (14)Unit weight: Approx. 4g .14oz.

Features

DS2Y-SL2-DC5V features: (1)2 Form C contact; (2)High sensitivity-200 mW nominal operating power; (3)High breakdown voltage 1500 V FCC surge between open contacts; (4)DIP-2C type matching 16 pin IC socket; (5)Sealed construction.
