Product Summary
The SCAN928028TUF is an 8 Channel 10:1 Serializer. The SCAN928028TUF can simultaneously serialize up to eight 10-bit data streams. The 10-bit parallel inputs are LVTTL signal levels. The serialized outputs are LVDS signals with extra drive current for point-to-point and lightly loaded multidrop applications. Each serializer block in the SCAN928028TUF operates independently by using strobes from a single shared PLL. The SCAN928028TUF uses a single +3.3V power supply with a typical power dissipation of 740mW (3.3V / PRBS / 66 MHz). Each serializer channel has a unique power down control to further conserve power consumption.
Parametrics
SCAN928028TUF absolute maximum ratings: (1)Supply voltage (VCC): -0.3V to +4V; (2)LVCMOS/LVTTL input voltage: -0.3V to (VCC +0.3V); (3)Bus LVDS driver output voltage: -0.3V to +3.9V; (4)Bus LVDS output short circuit duration: 10ms; (5)Package thermal resistance, θJA 196 LBGA: 34°C/W; θJC 196 LBGA: 8°C/W; (6)Storage temperature: -65°C to +150°C; (7)Junction temperature: +125°C; (8)Lead temperature (soldering, 4 seconds): +225°C; (9)ESD rating (HBM): ±1.5kV; (10)Reliability information transistor count: 37.5k.
Features
SCAN928028TUF features: (1)IEEE 1149.1 (JTAG)Compliant and At-Speed BIST test mode; (2)All 8 channels synchronous to one parallel clock rate, from 25 to 66 MHz; (3)Duplicates functioof multiple DS92LV1021 and 1023 10-bit Serializer devices; (4)Serializes from one to eight 10-bit parallel inputs into data streams with embedded clock; (5)Eight 5 mA modified Bus LVDS outputs that are capable to drive double terminations; (6)Speed Test - PRBS generatioto check LVDS transmissiopath to SCAN921224, SCAN921226, SCAN921260, or SCAN926260; (7)Ochip filtering for PLL; (8)740mW typ power dissipatio(loaded, PRBS, 66MHz, 3.3V); (9)High impedance inputs and outputs opower off; (10)Single power supply at +3.3V (+/-10%); (11)196-piLBGA package; (12)Industrial temperature range operation: -40 to +85°C.
