SN74LVCH16244ADGGR

SN74LVCH16244ADGGR, 16-bit buffer / driver, 70°C/W, 6.5 V, TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.46~1.62 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 500 :	1.62 / Piece
500 ~ 1000 :	1.54 / Piece
1000 ~ 1500 :	1.46 / Piece

PartNumber:: SN74LVCH16244ADGGR

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 00+

Availability:: Supply Ability: 10000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. harry's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-09

From Other Seller

Part Number:SN74LVCH16244ADGGR
US $1.46 - 1.62
Quantity:

piece

Product Summary

The SN74LVCH16244ADGGR is a 16-bit buffer / driver. It is designed specifically to improve the performance and density of 3-state memory address drivers, clock drivers, and bus-oriented receivers and transmitters. The device can be used as four 4-bit buffers, two 8-bit buffers, or one 16-bit buffer. It provides true outputs and symmetrical active-low output-enable (OE) inputs.

Parametrics

SN74LVCH16244ADGGR absolute maximum ratings: (1)Supply voltage range, VCC: -0.5 V to 6.5 V; (2)Input clamp current, IIK: -50 mA; (3)Voltage range applied to any output in the high-impedance or power-off state: -0.5 V to 6.5 V; (4)Input voltage range, VI: –0.5 V to 6.5 V; (5)Output clamp current, IOK: +/-50 mA; (6)Package thermal impedance: 70°C/W; (7)Storage temperature range: -65°C to 150°C.

Features

SN74LVCH16244ADGGR features: (1)Member of the Texas Instruments Widebus Family; (2)Operates From 1.65 V to 3.6 V; (3)Inputs Accept Voltages to 5.5 V; (4)Max tpd of 4.1 ns at 3.3 V; (5)Typical VOLP (Output Ground Bounce) <0.8 V at VCC = 3.3 V, TA = 25°C; (6)Typical VOHV (Output VOH Undershoot) >2 V at VCC = 3.3 V, TA = 25°C; (7)Ioff Supports Partial-Power-Down Mode Operation; (8)Supports Mixed-Mode Signal Operation on All Ports (5-V Input/Output Voltage With 3.3-V VCC); (9)Bus Hold on Data Inputs Eliminates the Need for External Pullup/Pulldown Resistors; (10)Latch-Up Performance Exceeds 250 mA Per JESD 17.
