Product Summary
The TDA1085C is a phase angle triac controller which has all the necessary functions for universal motor speed control in washing machines. It operates in closed loop configuration and provides tworamp possibilities. Motor speed is digitally sensed by a tachogenerator and then converted into an analog voltage.
The speed set is externally fixed and is applied to theinternal linear regulation input after having been submitted to programmable acceleration ramps. The overall result consists in a full motor speed range with two accelerationramps which allow efficient washing machine control(Distribute function).
Additionally, the TDA1085C protects the whole systemagainst AC line stop or variations, overcurrent in the motorand tachogenerator failure
Parametrics
The absolute maximum ratings of TDA1085C are
(1)Power Supply, when externally regulated,VPin 9 VCC: 15V;
(2)Maximum Voltage: 0 to + VCC V;
(3)Maximum Power Dissipation PD:1.0W;
(4)Thermal Resistance, Junction-to-Air RqJA: 65°C/W;
(5)Operating Junction Temperature TJ:-10 to +120°C;
(6)Storage Temperature RangeTstg:-55 to +150°C
Features
The features of TDA1085C can be summarized as
(1)On-Chip Frequency to Voltage Converter;
(2)On-Chip Ramps Generator;
(3)Soft-Start;
(4)Load Current Limitation;
(5)Tachogenerator Circuit Sensing;
(6)Direct Supply from AC Line;
(7)Security Functions Performed by Monitor;
(8)Pb-Free Package is Available
