Product Summary
The TMS320DM320ZHK is a highly integrated, programmable platform for digital still camera, digital photo frames, IP security cameras, 4-channel digital video recorders, video door bell application, and other low cost portable digital video applications. The TMS320DM320ZHK also enables seamless interface to most additional external devices required for a complete digital camera implementation. The TMS320DM320ZHK has a Video Processing Subsystem (VPSS) with two configurable video/imaging peripherals.
Parametrics
TMS320DM320ZHK absolute maximum ratings: (1) Supply voltage ranges: -0.5 to 1.7V (All 1.3 V supplies) , -0.5 to 2.5V (All digital 1.8 V supplies) , 4.4V (All analog 1.8 V supplies) ; (2) Input voltage ranges: -0.5 to 4.4V (All 1.8V I/Os) , -0.5 to 3.8V (All 3.3 V I/Os) ; (3) Clamp current for input or output: -20 to 20mA; (4) Operating case temperature ranges: -40 to 100°C; (5) Storage temperature ranges: -65 to 150°C.
Features
TMS320DM320ZHK features: (1) High-Performance Digital Media System-on-Chip; (2) ARM926EJ-S Core; (3) ARM9 Memory Architecture; (4) Video Processing Subsystem; (5) Enhanced Direct-Memory-Access (EDMA) Controller (64 Independent Channels) ; (6) Two Audio Serial Port (ASP) ; (7) Up to 104 General-Purpose I/O (GPIO) Pins Back End Provides: (Multiplexed with Other Device Functions) ; (8) On-Chip ARM ROM Bootloader (RBL) to Boot From NAND Flash, MMC/SD, or UART.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() TMS320DM320ZHK |
![]() Texas Instruments |
![]() Processors - Application Specialized DM320 Rev1.1 |
![]() Data Sheet |
![]()
|
|
||||||||||||
