Product Summary
This series of UA78L05ACDR of fixed-voltage integrated-circuitvoltage regulators is designed for a wide range ofapplications. These applications include on-cardregulation for elimination of noise and distributionproblems associated with single-point regulation.In addition, they can be used with power-passelements to make high-current voltage regulators.One of these regulators can deliver up to 100 mA of output current. The internal limiting andthermal-shutdown features of these regulators essentially make them immune to overload. When used as a replacement for a Zener diode-resistorcombination, an effective improvement in outputimpedance can be obtained, together with lowerbias current.
Parametrics
The absolute maximum ratings of UA78L05ACDR are
(1)Input voltage, VI: 30 V;
(2)Virtual junction temperature, TJL: 150°C;
(3)Storage temperature range, Tstg: -65°C to 150°C
Features
The features of UA78L05ACDR can be summarized as
(1)3-Terminal Regulators;
(2)Output Current Up To 100 mA;
(3)No External Components;
(4)Internal Thermal-Overload Protection;
(5)Internal Short-Circuit Current Limiting
Diagrams
<DIV><IMG alt="UA78L05ACDR Pin Configuration" src="http://www.seekic.com/uploadfile/ic-mfg/2012711204822724.jpg" border=0></DIV>
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() UA78L05ACDR |
![]() Texas Instruments |
![]() Linear Regulators - Standard 5.0V 100mA |
![]() Data Sheet |
![]()
|
|
||||||||||||
![]() |
![]() UA78L05ACDRE4 |
![]() Texas Instruments |
![]() Linear Regulators - Standard 5V 100mA Fixed Pos Voltage Regulator |
![]() Data Sheet |
![]()
|
|
||||||||||||
![]() |
![]() UA78L05ACDRG4 |
![]() Texas Instruments |
![]() Linear Regulators - Standard 5V 100mA Fixed Pos Voltage Regulator |
![]() Data Sheet |
![]()
|
|
