Product Summary
The UCC1800/1/2/3/4/5 family of high-speed, low-power integrated cir-cuits contain all of the control and drive components required for off-lineand DC-to-DC fixed frequency current-mode switching power supplies with minimal parts count.
These devices have the same pin configuration as the UC1842/3/4/5family, and also offer the added features of internal full-cycle soft startand internal leading-edge blanking of the current-sense input.
the UCC380x series is specified for operation from 0°C to +70°C.
Parametrics
The absolute maximum ratings of UCC3802D are
(1)VCC Voltage (Note 2): 120V;
(2)VCC Current (Note 2): 300mA;
(3)OUT Current: ±10A;
(4)OUT Energy (Capacitive Load): 200μJ;
(5)Analog Inputs (FB, CS): –03V to 63V;
(6)Power Dissipation at TA < +25°C (N or J Package): 10W;
(7)Power Dissipation at TA < +25°C (D Package): 065W;
(8)Power Dissipation at TA < +25°C (L Package): 1375W;
(9)Storage Temperature Range: –65°C to +150°C;
(10)Lead Temperature (Soldering, 10 Seconds): +300°C
Features
The features of UCC3802D can be summarized as
(1)100μA Typical Starting Supply Current;
(2)500μA Typical Operating Supply Current;
(3)Operation to 1MHz;
(4)Internal Soft Start;
(5)Internal Fault Soft Start;
(6)Internal Leading-Edge Blanking of theCurrent Sense Signal;
(7)1 Amp Totem-Pole Output;
(8)70ns Typical Response fromCurrent-Sense to Gate Drive Output;
(9)1.5% Tolerance Voltage Reference Same Pinout as UC3842 and UC3842A
Diagrams
<DIV><IMG alt="UCC3802D Pin Configuration" src="http://www.seekic.com/uploadfile/ic-mfg/201271120922662.jpg" border=0></DIV>
