USB1T11ABQX

USB1T11ABQX, one chip generic USB transceiver, 7.0V, 50 mA, 12Mbit/s, QFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.80~6.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 500 :	6.80 / Piece
500 ~ 1000 :	4.95 / Piece
1000 ~ 1500 :	2.80 / Piece

PartNumber:: USB1T11ABQX

Brand:: Fairchild Semiconductor - Fairchild | Pack: QFN | D/C: 08+

Availability:: Supply Ability: 10000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. harry's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-30

From Other Seller

Part Number:USB1T11ABQX
US $2.80 - 6.80
Quantity:

piece

Product Summary

The USB1T11ABQX is an one chip generic USB transceiver. The USB1T11ABQX is designed to allow 5.0V or 3.3V programmable and standard logic to interface with the physical layer of the Universal Serial Bus. The USB1T11ABQX is capable of transmitting and receiving serial data at both full speed (12Mbit/s) and low speed (1.5Mbit/s) data rates. The input and output signals of the USB1T11ABQX conform with the “Serial Interface Engine”. Implementation of the Serial Interface Engine along with the USB1T11ABQX allows the designer to make USB compatible devices with off-theshelf logic and easily modify and update the application.

Parametrics

USB1T11ABQX absolute maximum ratings: (1)DC Supply Voltage (VCC): -0.5V to +7.0V; (2)DC Input Diode Current (IIK), VI < 0: -50 mA; (3)Input Voltage (VI): -0.5V to +5.5V; (4)Input Voltage (VI/O): -0.5V to VCC +0.5V; (5)Output Diode Current (IOK), VO > VCC or VO &< 0: ±50 mA; (6)Output Voltage (VO): -0.5V to VCC +0.5V; (7)Output Source or Sink Current (IO), VP.VM, RCV pins, VO = 0 to VCC: ±15 mA; (8)Output Source or Sink Current (IO), D+/D- pins, VO = 0 to VCC: ±50 mA; (9)VCC or GND Current (ICC, IGND): ±100 mA; (10)Storage Temperature (TSTO): -60℃ to +150℃.

Features

USB1T11ABQX features: (1)Complies with Universal Serial Bus specification 1.1; (2)Utilizes digital inputs and outputs to transmit and receive; (3)USB cable data; (4)Supports 12Mbit/s “Full Speed” and 1.5Mbit/s “Low Speed” serial data transmission; (5)Compatible with the VHDL “Serial Interface Engine” from USB Implementers’ Forum; (6)Supports single-ended data interface; (7)Single 3.3V supply; (8)ESD Performance: Human Body Model, 9.5 kV on D-, D+ pins only; 4 kV on all other pins; (9)16-lead Pb-Free MLP package saves space.
