Product Summary

The W80NE06-10 is a power MOSFET. It is the latest development of STMicroelectronics unique "Single Feature Size" strip-based process. And it can be used in (1)solenoid and relay drivers; (2)motor control, audio amplifiers; (3)dc-dc converters; (4)automotive environment.

Parametrics

W80NE06-10 absolute maximum ratings: (1)Drain-source Voltage (VGS = 0): 60 V; (2)Drain- gate Voltage (RGS = 20 kW): 60 V; (3)Gate-source Voltage: ±20 V; (4)Drain Current (continuous) at Tc = 25°C: 80 A; (5)Drain Current (continuous) at Tc = 100°C: 57 A; (6)Drain Current (pulsed): 320 A; (7)Storage temperature range: -65°C to 175°C; (8)Total Dissipation: 200 W; (9)Derating Factor: 1.33 W/°C.

Features

W80NE06-10 features: (1)TYPICAL RDS(on) = 0.0085 Ω; (2)exceptional dv/dt capability; (3)100% avalanche tested; (4)application oriented characterization.

Diagrams

W80NE06-10 pin connection
