Product Summary
The MDD56-16N1B is a diode module. It is ideal for (1)Supplies for DC power equipment; (2)DC supply for PWM inverter; (3)Field supply for DC motors; (4)Battery DC power supplies.
Parametrics
MDD56-16N1B absolute maximum ratings: (1)IR TVJ = TVJM; VR = VRRM: 10 mA; (2)VF IF = 200 A; TVJ = 25°C: 1.48 V; (3)VT0 For power-loss calculations only: 0.8 V; (4)IRM: 24 A; (5)TVJ: -40 to +150°C; (6)TVJM: 150°C; (7)Tstg: -40 to +125°C.
Features
MDD56-16N1B features: (1)International standard package JEDEC TO-240 AA; (2)Direct copper bonded Al2O3 -ceramic base plate; (3)Planar passivated chips; (4)Isolation voltage 3600 V; (5)UL registered, E 72873.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 MDD56-16N1B |
Ixys |
Discrete Semiconductor Modules 56 Amps 1600V |
Data Sheet |
Negotiable |
|
||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||
|
MDD56-08N1B |
Ixys |
Discrete Semiconductor Modules 56 Amps 800V |
Data Sheet |
Negotiable |
|
||||
|
MDD56-12N1B |
Ixys |
Discrete Semiconductor Modules 56 Amps 1200V |
Data Sheet |
Negotiable |
|
||||
|
MDD56-14N1B |
Ixys |
Discrete Semiconductor Modules 56 Amps 1400V |
Data Sheet |
Negotiable |
|
||||
|
MDD56-16N1B |
Ixys |
Discrete Semiconductor Modules 56 Amps 1600V |
Data Sheet |
Negotiable |
|
||||
|
MDD56-18N1B |
Ixys |
Discrete Semiconductor Modules 56 Amps 1800V |
Data Sheet |
Negotiable |
|
||||
