Product Summary
The MGFS45V2527 is an internally impedance-matched GaAs power FET especially designed for use in 2.5 - 2.7GHz band amplifiers.The hermetically sealed metal-ceramicpackage guarantees high reliability.
Parametrics
MGFS45V2527A absolute maximum ratings: (1)High output power P1dB = 32W (TYP.) @ f=2.5 - 2.7 GHz; (2)High power gain GLP = 12 dB (TYP.) @ f=2.5 - 2.7GHz; (3)High power added efficiency P.A.E. = 45 % (TYP.) @ f=2.5 - 2.7GHz; (4)Low distortion [item -51]IM3=-45dBc(TYP.) @Po=34.5 dBm S.C.L.
Features
MGFS45V2527A features: (1)VGDO: Gate to drain voltage -15V ; (2)VGSO: Gate to source voltage -15V; (3)ID: Drain current 22A.
