Product Summary
The 2SK1300 is a Silicon N-Channel MOS FET. It is widely used in High speed power switching.
Parametrics
2SK1300 absolute maximum ratings: (1)Drain to source voltage VDSS: 100 V; (2)Gate to source voltage VGSS: ±20 V; (3)Drain current ID: 10 A; (4)Drain peak current ID(pulse)*1: 40 A; (5)Body to drain diode reverse drain current IDR: 10 A; (6)Channel dissipation Pch*2: 40 W; (7)Channel temperature Tch: 150 °C; (8)Storage temperature Tstg: –55 to +150 °C.
Features
2SK1300 features: (1)Low on-resistance; (2)High speed switching; (3)Low drive current; (4)4 V gate drive device Can be driven from 5 V source; (5)Suitable for motor drive, DC-DC converter, power switch and solenoid drive.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 2SK1300 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
