Product Summary
The DM74LS165N is an 8-bit serial shift register which shifts data in the direction of QA toward QH when clocked. Parallel-in access is made available by eight individual direct data inputs, which are enabled by a low level at the shift/load input. These registers also feature gated clock inputs and complementary outputs from the eighth bit.
Parametrics
DM74LS165N absolute maximum ratings: (1)Supply Voltage: 7V; (2)Input Voltage: 7V; (3)Operating Free Air Temperature Range: -55 ℃ to +125℃; (4)Storage Temperature Range: -65℃ to +150℃.
Features
DM74LS165N features: (1)Complementary outputs; (2)Direct overriding (data)inputs; (3)Gated clock inputs; (4)Parallel-to-serial data conversion; (5)Typical frequency 35 MHz; (6)Typical power dissipation 105 mW.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 DM74LS165N |
Fairchild Semiconductor |
Counter Shift Registers 8-Bit Serial Sht Reg |
Data Sheet |
Negotiable |
|
||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||
 |
DM7400 |
Other |
|
Data Sheet |
Negotiable |
|
||||
 |
DM7400N |
Fairchild Semiconductor |
IC GATE NAND QUAD 2INP 14-DIP |
Data Sheet |
Negotiable |
|
||||
|
DM7401 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
DM7402 |
Other |
|
Data Sheet |
Negotiable |
|
||||
 |
DM7402N |
|
IC GATE NOR QUAD 2INP 14-DIP |
Data Sheet |
Negotiable |
|
||||
|
DM7403 |
Other |
|
Data Sheet |
Negotiable |
|
||||
