Product Summary

The F2368VTE34V is a DCS/PCS low noise amplifier with bypass switch designed for use as a front-end for DCS1800/PCS1900 applications. The LNA is a two-stage amplifier with bypass switch. This amplifier has low noise figure and high linearity in both high gain and bypass/low gain mode. It is ideal for: (1)DCS Handsets; (2)PCS Handsets; (3)General Purpose Amplification; (4)Commercial and Consumer Systems.



Parametrics

F2368VTE34V absolute maximum ratings: (1)Supply Voltage: -0.5 to +6.0 VDC; (2)Input RF Level: +10 dBm; (3)Storage Temperature: -40 to +150 °C.

Features

F2368VTE34V features: (1)Low Noise and High Intercept Point; (2)Power Down Control; (3)Switchable Gain.

Diagrams

F2368VTE34V pin connection
