Product Summary

The fga25n120antdtu is a 1200V, 25A NPT trench IGBT. The fga25n120antdtu offers superior conduction and switching performances, high avalanche ruggedness and easy parallel operation. The fga25n120antdtu is well suited for resonant induction or soft switching application such a microwave oven. Applications of the fga25n120antdtu include: Induction Heating, Microwave Oven.

Parametrics

fga25n120antdtu absolute maximum ratings: (1) Collector-Emitter Voltage VCES: 1200V; (2) Gate-Emitter Voltage VGES: ±20V; (3) Collector Current Ic: 50A (@ Tc=25°C) , 25A (@Tc=100°C) ; (4) Pulsed Collector Current ICM: 90A; (5) Maximum Power Dissipation PD: 125°C; (6) Operating Junction Temperature Tj: -55 to +150°C; (7) Maximum Lead Temp. for soldering Purposes, 1/8 inch± from case for 5 second: 300°C.

Features

fga25n120antdtu features: (1) NPT Trench Technology, Positive Temperature Coefficient; (2) Low Saturation Voltage: VCE (sat) typ=2V@Ic=25A and TC= 25°C; (3) Low switching loss: Eoff typ=0.96mJ@Ic=25A and TC= 25°C; (4) Extremely Enhanced Avalanche Capability.

Diagrams

fga25n120antdtu circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
FGA25N120ANTDTU
FGA25N120ANTDTU
Fairchild Semiconductor
IGBT Transistors Copak Discrete
Data Sheet
0-1: $2.68
1-25: $2.42
25-100: $2.20
100-250: $1.99
FGA25N120ANTDTU_F109
FGA25N120ANTDTU_F109
Fairchild Semiconductor
IGBT Transistors Copak Discrete
Data Sheet
0-220: $2.11
220-250: $1.91
250-500: $1.72
500-1000: $1.45
