Product Summary

The FLI30436-AC is a Single-chip analog TV processor for LCD TV and Digital Audio Video applications. These solutions are capable of meeting global market requirements for: video and audio decoding and processing, Sound IF demodulation, and HDMI input support. It provides Faroudja DCDi Edge suite for advanced video and color processing. The applications of the FLI30436-AC include LCD TVs, Portable or handheld TVs.

Features

FLI30436-AC features: (1)Triple 10-bit ADC; (2)2D video decoder; (3)HDMI Rx (in case of FLI30602H); (4)Programmable digital input port (8/16 bits in FLI30602H and 24 bits in FLI30502); (5)Faroudja DCDi EdgeR image enhancement suite; (6)ACM-3D; (7)OSD controller; (8)Embedded microprocessor; (9)VBI slicer; (10)Worldwide SIF audio demodulator; (11)Audio processing; (12)Advanced audio enhancement; (13)Digital audio support; (14)I2S, SPDIF input; (15)I2S, SPDIF output; (16)Loud speaker, sub woofer, and headphone; (17)Analog line in, microphone in, and line out; (18)Tuner noise reduction.

Diagrams

FLI30436-AC block diagram
